5GETTING TO KNOW YOUR UNIT
1. Control panel
2. Drawer water tank: drawer for water
3. Drawer ice basket: drawer for ice
4. Drip tray
5. Unit shell
6. Water drain cap: after cleaning procedure, remove drain cap from the back
of the appliance, pull out the cap from the drainpipe, empty the tank under
the drawer, then reinsert the cap and put it back again.
7. Drainpipe: after cleaning procedure, you can collect dirty water from the
drainpipe (there are two pipes: one connects to the evaporator, the other one
connects to the water tank under the drawer)
8. Hot air outlet
9. Power cord
10. Cover: cover for drawer water tank
11. Lid: you can open the lid and pour the water into the tank
7
6
1
2
3
4
8
5
9
10
11
