Wall Sleeve Brands:
Rear Louvers
60°
10-1/2"
60°
Top View
#2 Fedders 19
3
⁄
4
"Deep
1. Redirect the louvers at the back of the wall sleeve as shown in the
illustration. The use of pliers is recommended.
2. Attach the (2) 4
1
⁄
2
"x 3
1
⁄
2
"x 1
1
⁄
2
"Centering/Support Blocks to the inside
of the walls of the wall sleeve as illustrate with tapered end facing
the opening of sleeve. These (2) blocks should be located
approximately in the center of the side walls. To attach the blocks
remove the backing paper from the blocks. Do not touch adhesive on
the blocks. Press the blocks firmly in place.
3. Cut (2) 17"Tapered Spacer Blocks and install as shown in the
illustration. The 4"portion to be placed in front of the rib on base and
tapered end facing the back of the sleeve. The remaining portion to
be placed behind the rib.
4. Attach (1) 1
1
⁄
2
"x 1
1
⁄
2
"x 26
1
⁄
2
"long seals and the (2) 1
1
⁄
2
"x 1
1
⁄
2
"x 14"
long seals as shown in the illustration.
5. Cut (1) 1
1
⁄
2
'x 1
1
⁄
2
"x 26
1
⁄
2
"long seal to 14"and attach to inside of the
louvered panel as shown in the illustration.
6. Install the new unit into the wall sleeve.
8. Install the 1"x 1
1
⁄
2
"x 84"long stuffer seal between the wall sleeve
and the unit. Aflat bladed screwdriver or putty knife is recommended.
9. Assemble and install the Trim Frame.
(see Trim Frame)
7. Attach the ground wire to the unit as
shown.
Cut Here
3/4"
17"
4"
1"
Protection Paper Backing
Tapered Spacer Block
2
2
3
4
5
8
8
7
←10
1
⁄
2
"‹→
←6
1
⁄
2
"‹→ ←6
1
⁄
2
"‹→
3
To Next Page
