Wall Sleeve Brands:
Rear Louvers
60°
10-1/2"
60°
Top View
#3 Fedders or Friedrich 16
3
⁄
4
"Deep
1. Redirect the louvers at the back of the wall sleeve as shown in the
illustration. The use of pliers is recommended.
2. Attach (2) 4
1
⁄
2
"x 3
1
⁄
2
"x 1
1
⁄
2
"Centering/Support Blocks to the inside of
the walls of the wall sleeve as illustrated with tapered end facing the
opening of the Sleeve. These (2) blocks should be located
approximately in the center of the side walls. To attach the blocks
remove the backing paper from the blocks. Do not touch adhesive on
the blocks. Press the blocks firmly in place.
3. Cut (2) 17"Tapered Spacer Blocks and install as shown in the
illustration. The 4"portion to be placed in front of the rib on base and
tapered end facing the back of the sleeve. The remaining portion to
be placed behind the rib. The 2
1
⁄
2
"portion to be placed in front of the
rib on the base with the tapered end facing the back of the sleeve.
Cut the remaining portion to 12
1
⁄
2
"and place behind the rib with the
tapered end facing the back of the sleeve.
4. Attach (1) 1
1
⁄
2
"x 1
1
⁄
2
"x 26
1
⁄
2
"long seals and the
(2) 1
1
⁄
2
"x 1
1
⁄
2
"x 14"long seals as shown in the illustration.
5. Cut (1) 1
1
⁄
2
"x 1
1
⁄
2
"x 26
1
⁄
2
"long seal to 14"and attach inside of the
louvered panel as shown in the illustration.
7. Install the 1"x 1
1
⁄
2
"x 84"long stuffer seal between the wall sleeve and the unit.
Aflat bladed screwdriver or putty knife is recommended.
6. Install the new unit into the wall sleeve.
Attach the ground wire to the unit as shown.
8. Assemble and install the Trim Frame.
(see Trim Frame)
Cut Here
3/4"
17"
1"
Protection Paper Backing
Tapered Spacer Block
12-1/2"12-1/2"
2-1/2"
2
2
3
4
5
4
4
7
7
←10
1
⁄
2
"‹→
←6
1
⁄
2
"‹→ ←6
1
⁄
2
"‹→
6
4
To Next Page
