Air Conditioner Features
CONTROL PANEL
FAN SPEED SELECTION
MODE SELECTION
(NOTE: HEAT AVAILABLE
ON SELECT MODELS)
BUCKET FULL INDICATOR
POWER INDICATOR
ON / OFF BUTTON
TIMER BUTTONS
REMOTE SIGNAL
RECEIVER
TEMPERATURE
CHANGE BUTTONS
TEMP / TIMER
DISPLAY
FAHRENHEIT / CELSIUS
INDICATORS
Fig.3
REMOTE CONTROL
MODE INDICATION
MODE SELECTOR
FAN SPEED
SELECTOR
FAN SELECTION
TEMPERATURE
CONTROL BUTTONS
TIMER BUTTONS
ON/OFF BUTTON
RESET + LOCK
PIN BUTTONS
