Section 2 Installation Information
2-2
Tools and Materials Needed for
Installation
• Drill, Electric
• Driver, Socket 1/4” , 5/16”
• Flaring Tool / Tube Cutter (for copper tubing)
• Flashlight
• Level
• Pipe Joint Compound (for iron pipe plumbing) or
Pipe Thread Tape (for sealing threads)
• Pliers
• Safety Glasses
• Saw, Keyhole or 1/2”, 1-1/2” to 2” Hole Cutters
• Screw Drivers, Slotted and #2 Phillips (magnetic tip
preferred)
• Tape, Electrical or Duct
• Tape, Measuring
• Wire Stripper or Utility Knife
• Wrench, Hex-end
• Wrenches, 2 Adjustable (for copper tubing) or 2 Pipe
wrenches (for iron pipe plumbing)
Parts You Will Need *(Not Included)
• Conduit Connector
• Drain Hose Clamp, 11/4” Diameter
• Elbow, 90° with a 3/8” National Pipe Thread
• Wire Nuts, UL listed (3)
• Strain Relief
* If required:
• “Y” Branch Tailpiece and Connector Kit, Available at
Plumbing Supply Store.
• Air Gap Kit, Available at Plumbing Supply Store.
• Fasteners for floor anchoring, Available at Hardware
Store
• Hand Shut-off Valve, Available at Plumbing Supply
Store.
Disconnect electrical power at the fuse box or circuit
breaker box before beginning installation. Failure to
follow this warning could result in death or serious
injury.
Read all instructions before installing dishwasher.
For your safety, please read and observe all safety
instructions.
WARNING
The dishwasher must be connected to a grounded
metal, permanent wiring system. The equipment
grounding conductor must be run with the circuit
conductors and connected to the appliances’
equipment grounding terminal or lead. It is the
consumers responsibility to contact a qualified installer
to make sure the electrical installation conforms with
the National Electrical Code and local codes and
ordinances.
Do not connect the dishwasher to the power supply
until the appliance is permanently grounded.
All wiring connections must be enclosed in the junction
box. This unit has copper lead wires. Joining
aluminum building wire to stranded copper wire should
be done by a qualified electrician using materials
recognized by UL and local codes.
Do not use an extension cord. Such use can result in
fire, electrical shock, or other personal injury.
Failure to follow these instructions could result in
death or serious injury.
WARNING
