Frigidaire FEB30T7DCB - Timed Bake Operation; Delayed Start Bake Operation; Adjusting Temperature or Bake Time

4
TERMINAL BOARD CONNECTORS
KEYBOARD
*Micro
Programming
P3 (2x17 pins)
P4 (6 pins)
Display
Board
Flash
and
eeprom
Display Beeper
*Micro
Programming
P1 (9 pins) J1 (9 pins)
P29 (6)
P27-5
P27-3
P27-6
P27-7
P27-10
P27-9
RTD Common 1
RTD 1
Door 1 Unlock
Door 1 Lock
Door Lock 1 Common
Door 1 Position
RTD Common 2
RTD 2
Door 2 Unlock
Door 2 Lock
Door Lock 2 Common
Door 2 Position
P28-4
P28-3
P28-6
P28-7
P28-8
P28-9
L 2
L 1
K8
K1
P8
P25
P31-2
P31-1
P33-4
P18
P11
P10
P9
P1
P24
Lower Conv Fan
(K15)
Lower Cooling Fan
(K14)
Upper Conv Fan
(K12)
Lower Conv Ring
(K11)
Lower Bake
(K10)
Lower Broil
(K9)
P33-2
P33-1
P32-3
P17
P4
P3
P2
OR P34
P32-1
L1 L1
P33-5 OR P19
Upper Cooling Fan
(K7)
Upper Light
(K6)
Lower Light
(K5)
Upper Conv Ring
(K4)
Upper Bake
(K3)
Upper Broil
(K2)
Lower MDL (K16)
Upper MDL (K13)
P31-4
P33-7
N
Power
Board
Flash
N
L
1
P1 & J1 Pin Designations:
1- Filament 1
2- Filament 2
3- Ground
4- Vdisp
5- RS485 Comm1
6- Rs485 Comm2
7- +12V
8- Not used
9- Second PB
* Micro Programming
1 - MISO 2 - +5V
3 - SCK 4 - MOSI
5 - Reset 6 - GND
P23
P22
P20
P21
DLB
DLB
