FEB500CE Pub li ca tion No.
5995322988
# = Func tional Part 5 05/99
* = Non-Illustrated Part
CAVITY / ELEMENTS
A = FEB500CE (FEB500CESI)
B = FEB500CE (FEB500CEBI)
POS. NO PART NO DE SCRIP TION
2 5303298946 A B Shield oven-top
2A 5303305035 A B Shield-insulation
6 5303296873 A B Rack-oven
9 5303317977 A B Pan-broiler
10 5303317976 A B In sert broiler pan
12# 5301314211 A B Switch-light
14 5308011085 A B Socket-light/lamp
15 3201908 A B Lamp-oven light
16 3201911 A B Glass-oven light lens
17 5304400195 A B Re tainer-lens
27 5303284616 A B Clip thermo-bulb
41 5303310526 A B Cover hinge cut out/ Plaque décorative
54 5303310514 A B Housing-oven light
56 5303302711 A Trim-bodyside white
56 5303298951 B Trim-bodyside black
58A 5303304702 A B In su la tion oven wrapper
58B 5303299688 A B In su la tion oven back
59 318072507 A B Tube-oven vent
62# 5303310518 A B Ter mi nal block
66# 5303322963 A B El e ment-broil
67# 3202440 A B El e ment-bake
68 5304403015 A B Sup port-element
71 5303305037 A B Shield-wire
76 318056122 A B Front-oven
80 5303301261 A B Spring-oven
81 5303323710 A B Bracket-oven
82 5303305035 A B Shield in su la tion/ Panneau isolant
83 318089509 A B Liner-oven assy
86 5303310524 A B Chan nel-hinge
97 318066602 A B Wrap per-back side
98 318029322 A B Trim side in ner RH
98A 318029323 A B Trim side in ner LH
99 5303299686 A B Sup port-adjustable
101 318039512 A Bracket-trim
101 318039511 B Bracket-trim
103 318028711 A Trim-base white
103 318028710 B Trim-base black
119 3202388 A B Switch-thermal
121 318145001 A B Wrap per-base
127 5303310542 A B Adapter assy
189 318042500 A B Re tainer plate
227 5303323955 A B Clip-retainer
231 5303300421 A B Cover-capillary
* 08002868 A B Screw, 10-24 X ½
* 5303211311 A B Screw, #8 X ½
*# 5303319468 A B Box & wires assy
* 5303324184 A B Screw, 8 X 5/16
* 5303320422 A B Screw, 6-20 X 5/16
* 5303302745 A B Screw, 10-16 X 1 1/8/ Vis
* 5303935083 A Screw, 10-16 X 1 ¼ white/ Vis
