Frigidaire FEC30S6H - Maintop and Surface Units Parts List

FEC30S6H Pub li ca tion No.
5995323911
# = Func tional Part 5 05/99
* = Non-Illustrated Part
POS. NO PART NO DE SCRIP TION
15 318178101 A B El e ment-surface,2100W
15A# 318178002 A B El e ment-surface,1000/2000W
15B# 318178100 A B El e ment-surface 1200W
16 318079311 A Glass Main Top & frame white
16 318079310 B Glass Main Top & frame black
20 318121902 A B Bracket
23 5303297401 A B Panel-access
46 318077211 A B Burner Box
52 318122007 A B Spring el e ment mtg
52B 318122006 A B Spring el e ment mtg
159 318125111 A B De flec tor
162 318125200 A B Heat de flec tor
163 08007817 A B Spacer
164 318125301 A B Shield
*# 5303323364 A B Bx & wires assy
* 08016432 A B Screw, 8-18 X 3/8
* 5303323129 A B Screw, 8 X ¾
* 5303300265 A B Screw, 8-18 X ½
* 5303323131 A B Screw, 8-32 X 7/16
MAINTOP/SUR FACE UNITS
A= FEC30S6H (FEC30S6HSA)
B= FEC30S6H (FEC30S6HBA)
