6
WARNING
The anti-tip device must be
installed according to the
instructions in your Use &
Care Manual. Failure to do
so will result in injury.
WARNING
When reversing the door swing:
You MUST move the anti-tip bracket to align
with the hinges of the door. Failure to do so
will result in injury.
NOTE
Raise the front of the refrigerator enough so
the doors close freely when opened halfway.
The refrigerator should slope ¼ inch to
½ inch from front-to-back. Then level the
refrigerator from side-to-side.
To level the cabinet using the front
rollers:
1 Remove the toe grille.
2 Useaat-bladescrewdriveror⅜inch
socket wrench to raise or lower the front
rollers (Figure 2). Do not raise the cabinet
more than
9
/
16
inch.
Figure 4 (some models)
Lower
Anti-tip
Bracket
Raise
9/16"
Max
Figure 3
Figure 2
or
3 Use adjustable wrench to adjust leveling
screws. Lower the leveling screws on each
sideclockwiseuntiltheycontacttheoor
(Figure 3). Do not raise the cabinet more
than
9
/
16
inch.
4 Somemodelsareequippedwithananti-
tip bracket (Figure 4). Lower it clockwise
untilitcontactstheoor.
some models
INSTALLATION
