CONTROL PANEL
# = Funtional part
* = Non-illustrated part
FMT144G1B1, FMT144G1W1, FMT148G1B1, FMT148G1W1, FMT148G1T1, FMT148GPB1
FMT144G1B2, FMT144G1W2, FMT148G1B2, FMT148G1W2, FMT148G1T2, FMT148GPB2
Publication No. 5995338778
A = FMT144GB (FMT144G1B1 & FMT144G1B2)
B = FMT144GW (FMT144G1W1 & FMT144G1W2)
C = FMT148GB (FMT148G1B1 & FMT148G1B2)
D = FMT148GW (FMT148G1W1 & FMT148G1W2)
E = FMT148GT (FMT148G1T1 & FMT148G1T2)
F = FMT148GP (FMT148GPB1& FMT148GPB2)
POS NO. PART NO. DESCRIPTION
1# 5304408302 A B ---- Control Board, PCB
1# 5304408501 - - C D E F Control Board, PCB
2 5304408507 A ----- Control Panel-Black
2 5304408508 - B ---- Control Panel-White
2 5304408509 - - C - - F Control Panel-Black
2 5304408511 ---D-- Control Panel-White
2 5304408510 ----E- Control Panel-Almond
21 5304408514 A B ---- Bracket, Control Panel
21 5304408515 - - C D E - Bracket, Control Panel
21 5304408516 -----F Bracket, Control Panel
25# 5304408503 A ----- Membrane, Touchpad
25# 5304408303 - B ---- Membrane, Touchpad
25# 5304408502 - - C - - - Membrane, Touchpad
25# 5304408504 ---D-- Membrane, Touchpad
25# 5304408505 ----E- Membrane, Touchpad
25# 5304408506 -----F Membrane, Touchpad
27 5304408512 A B ---- Lens
27 5304408513 - - C D E F Lens
