# = Fast-moving Parts 11 08/00
* = Non-Illustrated Parts
FRS20QRC Publication No.
5995342515
A = FRS20QRC (FRS20QRCD9)
B = FRS20QRC (FRS20QRCW9)
POS. NO PART NO DESCRIPTION
2 5303308569 A B Knob-damper control
5 # 5308000010 A B Fan Blade,red
7 5308000124 A B Ring-fan orifice
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
12 215809600 A B Diffuser-air
13 # 218718402 A B Motor-evap fan
13* 215474201 A B Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B Bracket-motor mtg,rear
15 # 5303001179 A B Light Bulb/Lamp,40 W
16 # 5303289050 A B Socket-light/lamp
17 5303289049 A B Control Box,refr
17* 215188300 A B Screw-control box mtg, hex hd, 8-15A x 1.00,refr/frzr
17A 5303289056 A B Control Box,frzr
17A* 215980800 A B Brace-frzr cont box
18 5303308568 A B Knob-temp control,frzr
20 5303308567 A B Label-control box,refr
20A 5303308566 A B Label-control box,frzr
21 # 5303300027 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22 5303319683 A B Housing-temp sensor, plastic
22* 218731102 A B Tube, insulator, PVC, white, on temp sensor
23 # 215846606 A B Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 215277000 A B Cover-defrost timer,top
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B Shield-defrost timr,btm
41 5303001343 A B Screw,hex washer head ,8-15A x 0.500
41* 5303209814 A B Nut,"U" type ,8-15A ,fan mtr mtg
53 215809501 A B Box-damper control
65 5303001361 A B Pin-mounting,push-in ,plastic
74 218465001 A B Shield-light,frzr
75 218465101 A B Shield-light,refr
78 5303274237 A B Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B Bracket-connector
111 5303289024 A B Wireway,frzr
112 215277101 A B Rod-damper extn
113 5303289047 A B Cover-dmpr rod ext
114# 5303289051 A B Switch-light/lamp,white
115 215011503 A B Damper Assy,w/seal
116 215011400 A B Seal-damper,foam
CONTROLS
