# = Fast-moving Parts 11 01/02
* = Non-Illustrated Parts
PLHS237ZA Publication No.
5995364352
A = PLHS237ZA (PLHS237ZAB0)
B = PLHS237ZA (PLHS237ZAB1)
C = PLHS237ZA (PLHS237ZAB2)
D = PLHS237ZA (PLHS237ZAB3)
POS. NO PART NO DESCRIPTION
5 # 5308000010 A B C D Fan Blade,red ,evaporator fan
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303292396 A B C D Bracket-motor mtg,front
13 # 240315802 A B C D Motor-evap fan
13* 215474201 A B C D Washer,"slinger" ,nylon ,evap fan shaft
14 5303292397 A B C D Bracket-motor mtg,rear
15 240436701 A B C D Light Bulb/Lamp, A-15, 40 W, 120 V, miniature
16 218906801 A B C D Socket-light/lamp
17 240374901 A B C D Box-control,front
17* 240439901 A B C D Wiring Harness,controls
18 240360801 A B C D Knob-control
21 # 240375906 A - - - Control-temperature
21 # 240375903 - B C D Control-temperature
21A 5304421067 A B C D Control-temperature,frzr section
22 218660702 A B C D Tube-insulator
23 240375803 A B C D Control-defrost, adaptive timer, PC board
23* 5303001259 A B C D Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
45 241500301 A B C D Screw,hex washer head ,8-18AB x 0.500
53 240369501 A B C D Box-control
81 5308016566 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
115 240440701 A - - - Damper Assy,w/seal
115 240521101 - B C D Damper Assy,w/seal
115* 5304421593 A B C D Switch-micro,single pole,double throw,damper assy
137 240396401 A B C D Filter,water ,front ,cassette
137* 240396701 A B C D Bypass,water filter ,Optional Part
138 240397301 A B C D Button-filter release
139 240396001 A B C D Base-water filter
139* 240526901 A B C D O-ring,wtr filter base
149 240331601 A B C D Shroud-fan orfice
150 240394203 A B C D Insulation-water tube cover
151 240373805 A B C D Cover-water tube
198 240397401 A B C D Retainer
199 240397501 A B C D Rod
199* 240398401 A B C D Spring-filter release rod
200 240397601 A B C D Light Pipe
201 240398502 A B C D Label-control box
* 3205266 A B C D Edge Protector,wiring harness
* 240427201 A B C D Heater-freezer control
* 240470401 A B C D Connector-amp
CONTROLS
