# = Fast-moving Parts 13 01/02
* = Non-Illustrated Parts
PLHS237ZA Publication No.
5995364352
A = PLHS237ZA (PLHS237ZAB0)
B = PLHS237ZA (PLHS237ZAB1)
C = PLHS237ZA (PLHS237ZAB2)
D = PLHS237ZA (PLHS237ZAB3)
POS. NO PART NO DESCRIPTION
1 240333602 A B C D Condenser
3 218679606 A B C D Block-evap coil,styrofoam ,(2)
4 # 218944001 A B C D Drier-filter,R134a System
6 240346402 A B C D Harness-wiring,machine compt
6* 240315901 A B C - Harness-wiring
6* 240449602 ---D Harness-wiring
6* # 240439901 A B C D Wiring Harness,controls
14 5303918253 A B C D Defrost Heater Kit
15 # 5303918211 A B - - Evaporator Kit
15 # 5303918271 - - C D Evaporator Kit
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
21 5303918214 A B C D Thermostat-defrost,kit
22 240330002 A B C D Plate-compr mtg
23 218513300 A B C D Grommet-compr mtg,(4)
25 240491501 A B C D Screw-compr mtg, 1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B C D Pan-defrost drain
29 # 5303918251 A B C D Compressor,w/electricals
30 # 218721119 A B C D Starter-PTC
32 218973501 A B C D Clamp,elec cont mtg ,compressor
34 240405201 A B C D Grommet, rubber, black ,cond tube/wire
41 218897001 A B C D Screw, hex washer head ,8-32 x 1/4
41* 5308000039 A B C D Screw, hex wshr hd, 8-32CA x 0.500, serrated head
44 215174700 A B C D Clamp-service cord, strain relief, galv steel
45 5308016566 A B C D Screw,hex washer head, 8-15A x 0.625, low profile
55 # 216787800 A B C D Capacitor-run
57 240403601 A B C D Clip-wiring harness
58 215004600 A B C D Screw, hx wshr hd, 8-36 x 7/16, cond fan motor,(2)
59 240315501 A B C D Shroud-cond fan
59* 240346701 A B C D Tape-foam seal,shroud
59* 240359401 A B C D Screw-fan shroud,(2)
59A 240346501 A B C D Bracket-support,cond mtr ,(3)
59B 240346601 A B C D Grommet-bracket,(3)
60 # 240334001 A B C D Motor,condenser fan
61 # 240315401 A B C D Fan Blade,galv steel ,condenser fan
61A 215004700 A B C D Nut,speed
61B 215004800 A B C D Grommet-silencer
62 240429401 A B C D Trough-drain
70 218990801 A B C D Bracket-evap/cvr mtg
72 218397000 A B C D Button-handle mtg,dovetail
82 5304418225 A B C D Roller,compressor base ,rear ,(2)
83 5303316859 A B C D Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 5304421068 A B C D Tube-drain,lower
85 240346201 A B C D Tube-connector,suction
86 240409302 A B C D Spacer-cond tube,black
* # 5303918213 A B C D Heat Exchanger Kit,suction line
* 5303918222 A B C D Hot Tube Repair Kit,Service
SYSTEM
