# = Fast-moving Parts 15 01/02
* = Non-Illustrated Parts
PLHS237ZA Publication No.
5995364352
A = PLHS237ZA (PLHS237ZAB0)
B = PLHS237ZA (PLHS237ZAB1)
C = PLHS237ZA (PLHS237ZAB2)
D = PLHS237ZA (PLHS237ZAB3)
POS. NO PART NO DESCRIPTION
1 218976405 A B - - Tube-water inlet
1 218976410 - - C D Tube-water inlet
1* 218976901 A B C D Tube-water inlet, inlet valve to ice maker
1* 218976903 A B C D Tube-water inlet, inlet valve to filter
1* 218976907 A B C D Tube-water inlet, valve to door
4 5304422012 A B C D Cover-module, black
8 5304422013 A B C D Module-dispenser
10 5304421626 A B C D Spring-torsion
14 240323927 A B C D Label-module cover, black
15 5304421616 A B C D Light Bulb/Lamp
16 215284900 A B C D Socket-light/lamp
17 5304421619 A B C D Screw
23 240323603 A B C D Drip Tray, black
24 5304425585 A B C D Actuator-water, black
24A 5304425584 A B C D Actuator-ice, black
30 5304421628 A B C D Door Assy-ice chute
30A 5304421624 A B C D Door center
30B 5304421625 A B C D Insulation-door
30C 5304421629 A B C D Door seal
35 5304421620 A B C D Damper-rotary
36 5304421824 A B C D Carrier
38 5304422632 A B C D PC Board,power
38A# 5304421617 A B C D Switch-micro,single pole, double throw
38C 5304422633 A B - - PC Board,control
38C 5304426010 - - C D Board-control
39 5304421627 A B C D Pin-hinge
41 5304421829 A B C D Spring-actuator
43 215296300 A B C D Screw,plask h/l ,#6 x 3/8
43* 240363401 A B C D Screw-#8-18 X 1/2,#6 hd plask
56 5304421830 A B C D Screw-micro switch,pan head
87 5304421622 A B C D Bearing Plate
87A 5304421621 A B C D Bearing Plate
88 5304421615 A B C D Shield-light
90 5304421831 A B C D Light Pipe,reflector
91 5304421850 A B C D Light Pipe,reflector ,short
* 5303918256 A B C D Dispenser heater kit
DISPENSER
