# = Fast-moving Parts 3 01/02
* = Non-Illustrated Parts
PLHS237ZA Publication No.
5995364352
FREEZER DOOR
A = PLHS237ZA (PLHS237ZAB0)
B = PLHS237ZA (PLHS237ZAB1)
C = PLHS237ZA (PLHS237ZAB2)
D = PLHS237ZA (PLHS237ZAB3)
POS. NO PART NO DESCRIPTION
1 # 240390608 A B C D Gasket-frzr door,black ,magnetic
4A 240367302 A B C D Bin-door,frzr-upper
4B 240359002 A B C D Bin-door
4C 240358402 A B C D Bin-door,frzr-dispenser
11 240451835 A B C D Door-frzr,stainless steel, complete assy
13A 240456906 A B C D Door Stop,black ,frzr
18 240409801 A B C D Handle-door, stainless steel, with insert
21A 5308016566 A B C D Screw, hex washer head, 8-15A x 0.625, low profile
22A 240328202 A B C D Bearing-hinge,closer
22C 240328404 A B C D Bearing-hinge,black ,upper
68 240465801 A B C D Chute-ice
79 218755402 A B C D Screw-set,10-32 x 0.375
80 218755501 A B C D Screw-shoulder,#10 AB ,handle mounting
96 240345506 A B C D Plug,door foam hole ,black
* 218490900 A B C D Cleaner,stainless steel
* 240323202 A B C D Harness-wiring,door
* 240352101 A B C D Connector-water,straight
* 240470401 A B C D Connector-amp
* 5303918256 A B C D Dispenser heater kit
