8. INTERVENTIONS ON THE EQUIPMENT
8.1. Electronic board replacement
1. Loosen the central screw closing the front panel using a
screwdriver.
2. Lift the front panel, being careful to secure it to the
rear body.
3. Remove the electric box by loosening the two locking
screws using a screwdriver.
4. Open the plastic cable clamp with the help of a star-
tipped screwdriver.
5. Disconnect the connectors from the electronic board
terminal board.
6. Disconnect the earthing and the power supply.
