8.7. Door microswitch replacement
1. Loosen the central screw closing the front panel using a
screwdriver.
2. Lift the front panel, being careful to secure it to the
rear body.
3. Remove the electric box and disconnect the connection
connectors from the door microswitch.
4. Gently remove the door microswitch from the seat;
install the new door microswitch; connect the
connectors again.
5. Reposition the electric box on the seat, paying
attention to the cables.
6. Close the front panel paying attention to the door
microswitch.
