There are just a few things you will need to do to get your Frog ready to ride.
Follow these
5
simple steps and in a few minutes your child will be ready to pedal!
To begin, carefully remove all plastic wrapping, zip ties and cardboard wraps. We recommend saving
all packing material (for the time being) in case this bike is not the proper fit for your child.
STEP
1
: Install Handlebar
Remove the handlebar clamp plate by unscrewing the 4 bolts (using the 4mm Allen Wrench)
at the front of the stem.
Center the handlebar with even distance to each end on either side. The handlebar should be
oriented so that the brake lever on the rider’s right controls the rear brake.
Rotate the handlebar so that the angle of the brake levers are comfortable for your child. We
recommend angling the brake levers about
15-30 degrees down from the horizontal, but this can
always be adjusted.
Reinstall the handlebar clamp plate with the 4 bolts. When tight, there should still be a gap
between the handlebar clamp plate and the stem base. Try to make this gap roughly the same on
all
4 sides (top and bottom; left and right).
NOW LET’S GET STARTED!
When reinstalling the handlebar clamp plate, alternate tightening the bolts in an “X”
pattern for equal spacing around the clamp.
QUICK START ASSEMBLY
QUICK START ASSEMBLY:
1. Install Handlebar
2. Install Front Wheel
3. Install Pedals
4. Install & Adjust Saddle
5. Install Reflectors & Bell
*** SAFETY CHECK ***
1.
2.
3.
4.
5.
OPTIONAL INSTALLATIONS:
1. Install Mudguards
2. Install Full Chain Guard
3. Additional Accessories
1.
2.
3.
4
