29
• Lay umbrella on a soft clean surface. Pull and quarter turn rotation knob counter clockwise
to unlock internal stem from main frame. Remove internal stem from bottom of main
frame (Fig. 1).
• Select area to set base frame and place in desired location. NOTE: Moving the umbrella
will be difficult once fully assembled.
• Attach (4) feet with screws (Fig. 2) to bottom of base frame. Use wrench to adjust level of
base.
• Place internal stem on base frame and secure with (4) supplied hub bolts with 6mm
hexagon wrench (Fig. 3).
• Secure base frame with (4) 50 lbs. square stones or concrete weights (not included)
(Fig. 5).
IMPORTANT:
• Base frame will not support umbrella without proper weights. Using the stand without
weights will damage your umbrella and may cause injury.
Stone / Pavers
(not included)
IMPORTANT:
Prior to assembly it is important to decide on the location of the umbrella.
• Allow ample height to avoid damage to your umbrella during assembly and usage.
• Choose a location that is level and sturdy.
• Avoid any sloping of soft ground.
• Consider a location that will maximize the umbrella’s 360° rotating function. Placing the
umbrella between two entertaining areas is idea.
• When not in use, close and cover umbrella with provided protective cover.
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the cantilever pole. Pull the two panels together and roll tight
into the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with protective cover.
SAFETY PRECAUTIONS
CARE AND MAINTENANCE
STEP 1 Assemble Base Frame
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly and Operation Manual prior to
assembling and operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.
(Fig. 1) (Fig. 2)
(Fig. 3) (Fig. 4)
(Fig. 5)
