Frontier LS2004 - Page 28

5CS2004OM (rev 00 07/2020) 28
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
1 5CS61500 3 Point A Frame 1
2 5CS61502 Frame Base Left 1
3 5CS61503 Frame Base Right 1
4 5CS61504 Frame Base Rear 1
5 5CS61505 Boom Support 2
6 5CS43315 5/16” x 1-3/4” Square U-Bolt 2
7 03H1500 3/8” x 1” Carriage Bolt 6
8 E55662 3/8” Flange Nut 6
9 5CS43398 Lynch Pin 3
10 5CS43399 Top Link Pin, Cat 1 1
11 T58694 5/16” x 5/8” Flange Bolt 6
12 T406296 3/8” Flat Washer 4
13 5CS65007 5/16” x 3/4” Flange Bolt 8
14 A22698 5/16” Flange Nut 12
15 5CS43530 Tank 45 Gallon 1
16 5CS43981 Garden Hose Shut-off Valve 1
17 5CS43175 Tank Lid 6” 1
18 5CS62006 Hose Hanger 1
19 5CS61511 Cable Lanyard w/ I-hook 2
20 5CS43950 Manual Canister 1
21 5CS61512 S-hook 2
22 03H1701 1/4” x 3/4” Carriage Bolt 3
23 N10217 1/4” Flange Nut 3
- 5CS50912 Battery Harness 1 Not Illustrated
- 5CS50913 Chasis Harness 1 Not Illustrated
- 5CS50914 Switch Harness 1 Not Illustrated
- 5CS50915 Sprayer Extension Harness 1 Not Illustrated
- 5CS48616 Fir Tree w/ wire tie 1 Not Illustrated
- 5CS43984 Edge Clip w/ wire tie 1 Not Illustrated
- 5CS43985 Grommet 24.75 mm 1 Not Illustrated
- 5CS43986 Wire Tie, Black Nylon UV, 10” 10 Not Illustrated
Frame and Tank
Parts Diagrams
