Frontier LS2004 - Page 30

5CS2004OM (rev 00 07/2020) 30
2.2 GPM Pump and Hand Sprayer
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
6 5CS43181 Selector Valve 3/8” 1
7 5CS43182 Fitting Straight 3/8” Barb 2
8 5CS43258 Sump Strainer 3/8” 1
9 5CS65001 #10-24 x 1” Truss Head Screw 4
10 5CS43287 Spray Wand Clip Large 1
11 5CS43130 Spray Wand Clip Small 1
12 5CS43014 In-line Valve 3/8” 1
13 5CS43973 Harness Rentention Bracket 1
14 5CS43498 Plastic Wing Nut 1
15 5CS43499 3/8” Barb Fitting for Wing Nut 1
16 5CS65000 #10-24 x 3/8” Truss Head Screw 2
17 5CS43921
2.2 GPM Pump Head
Replacement
1
18 3/8” Hose 1
CTL 2.5”, MF
5CS43286
19 3/8” Hose 1
CTL 8”, MF
5CS43286
20 3/8” Hose 1
CTL 22”, MF
5CS43286
21 3/8” Hose 1
CTL 28”, MF
5CS43286
22 3/8” Hose 1
CTL 240”, MF
5CS43286
- 5CS43652
Hose Clamp Screw Type 3/8” -
1/2”
8 Not Illustrated
- 5CS43844 Grommet 5/8” ID 2 Not Illustrated
Parts Diagrams
