Frontier LS2006 - Parts Diagrams

5CS2006OM (rev 00 07/2020) 25
PARTS DIAGRAMS
Parts Diagrams
CAUTION
5HDGDQGXQGHUVWDQGWKH2SHUDWRU·V0DQXDOEHIRUHXVLQJ
7UDFWRUFDEPD\QRWSURYLGHVXIILFLHQWSURWHFWLRQ6HH7UDFWRU·V
2SHUDWRU·V0DQXDO
6WD\DZD\IURPFKHPLFDOVVSUD\DQGGULIW
%HIRUHVHUYLFLQJRUILOOLQJVSUD\HUORZHUDOOHTXLSPHQWWRWKH
JURXQGVHWWKHSDUNEUDNHVWRSWKHHQJLQHDQGUHPRYHWKHNH\
.HHSKDQGVIHHWKDLUDQGFORWKLQJDZD\IURPPRYLQJSDUWV
&OHDUWKHDUHDRIE\VWDQGHUVEHIRUHH[WHQGLQJRUIROGLQJERRPV
'RQRWDOORZULGHUV
.HHSRWKHUVDZD\
67
To avoid injury from chemical
hazards due to eye and skin contact,
inhalation, and ingestion, wear
personal protective equipment. Read
and follow chemical manufacturer’s
labels and instructions.
ST50927
WARNING
Safety Decals Kit and Model Decals
CAUTION
1. Read and understand the Operator’s Manual before using.
2. Tractor cab may not provide sufficient protection. See Tractor ’s
Operator’s Manual.
3. Stay away from chemicals, spray, and drift.
4. Before servicing or filling sprayer, lower all equipment to the
ground, set the park brake, stop the engine, and remove the key.
5. Keep hands, feet, hair, and clothing away from moving parts.
6. Clear the area of bystanders before extending or folding booms.
7. Do not allow riders.
8. Keep others away.
ST50910
To avoid injury from chemical
hazards due to eye and skin contact,
inhalation, and ingestion, wear
personal protective equipment. Read
and follow chemical manufacturer’s
labels and instructions.
ST50927
WARNING
LIQUID SPRAYER
OPERATOR'S MANUAL
LS2006
5CS2006OM (rev # MM/YYYY)
LS2006
Operator's Manual and Safety Decal Kit
CAUTION
1. Read and understand the Operator’s Manual before using.
2. Tractor cab may not provide sufficient protection. See Tractor ’s
Operator’s Manual.
3. Stay away from chemicals, spray, and drift.
4. Before servicing or filling sprayer, lower all equipment to the
ground, set the park brake, stop the engine, and remove the key.
5. Keep hands, feet, hair, and clothing away from moving parts.
6. Clear the area of bystanders before extending or folding booms.
7. Do not allow riders.
8. Keep others away.
ST50910
To avoid injury from chemical
hazards due to eye and skin contact,
inhalation, and ingestion, wear
personal protective equipment. Read
and follow chemical manufacturer’s
labels and instructions.
ST50927
WARNING
Replacement Decal Kit
1 - English
2 - French
3 - Spanish
4 - English
5 - French
6- Spanish
Qty. 3
Qty. 2
