5CS2006OM (rev 00 07/2020) 22
TROUBLESHOOTING
Troubleshooting Sprayer
Using the Troubleshooting Chart
If you are experiencing a problem that is not
listed in this chart, see your authorized dealer
for service.
When you have checked all the possible
causes listed and you are still experiencing the
problem, see your authorized dealer.
Troubleshooting Chart
IF CHECK
Pump Losses Suction
Clean pump suction screen.
Check tank ll level. Fill tank.
Clean or replace pump.
Check for loose pump ttings.
Pump Capacity
Decreased
Clean pump suction screen.
Clean spray nozzle(s).
Selection lever is not
completely turned on, or is in
the OFF position.
Poor Spray Pattern
Clean spray nozzles.
Adjust nozzle height.
Align spray tips with boom.
Pump Does Not Work Clean debris from pump.
