Frontier LS2006 - Page 28

5CS2006OM (rev 00 07/2020) 28 Parts Diagrams
Plumbing
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
10 5CS43630 3/4” Pipe Nipple 4
QTY 4 for 18ft Boom,
Qty 2 for 12.5 ft Boom
& 24ft Boomless
11 5CS43629 Single Union Ball Valve 1
12 5CS43631 Filter 1
13 5CS43632 Fitting 3/4” MP - 1” Hose 1
14 5CS43634 Control Valve 3
QTY 3 for 18ft Boom,
Qty 1 for 12.5 ft Boom
& 24ft Boomless
15 5CS43635 Relief Valve 3/4” 1
QTY 3 for 18ft Boom,
Qty 1 for 12.5 ft Boom
& 24ft Boomless
16 5CS43423 Fitting 1/2” Barb - 1/2 MP 3
17 5CS43987 Gauge 160 PSI 1
18 5CS43636 Fitting 3/4” MP - 3/4” barb 1
19 5CS43640
Tee, 3/4” Hose - 3/4” Hose -
3/4” FP
1
20 5CS43641 Fitting 3/4” MP - 1/2” Hose 1
