5CS2006OM (rev 00 07/2020) 30 Parts Diagrams
Hoses
ITEM NO.
PART
NUMBER
DESCRIPTION QTY. Note
6 1/2” Hose 1
For 30 ft Hand Sprayer
- CTL 360”, MF
5CS43418
For 100 ft Hose
Reel - CTL 1200” MF
5CS43418
- 5CS43652
Hose Clamp Screw Type 3/8” -
1/2”
6 Not Illustrated
- 5CS43653 Hose Clamp Screw Type 3/4” 6 Not Illustrated
- 5CS43654 Hose Clamp Screw Type 1” 2 Not Illustrated
- 5CS43426 1/2” barb tting for wing nut 1
Installed on item 5 for
12.5 ft Boom and 24 ft
Boomless
- 5CS43498 Plastic wing nut 1
Installed on item 5 for
12.5 ft Boom and 24 ft
Boomless
