Ref# Description Part# Ref# Description Part#

1 Nut, 3/8 5PQ000915 37 Bolt, 1/4 x 1-7/8 N/A

2 Lock Washer, 3/8 5PQ000820 38 Bolt, 5/16 x 2 N/A

3 Flatwasher, 3/8 5PQ001035 39 Key, 3/8 x 3/8 x 2 5PQ400857

4 Clamp Knob 5PQ900125 40 Lock Washer, 5/16 N/A

5 Deector 5PQ900030 41 Steel Locknut, 1/2 5PQ900144

6 Carriage Bolt, 3/8 x 1 5PQ000125 42 Rotor Paddle 5PQ900031

7 Chip Chute 5PQ900047 43 Belt, B-58 5PQ900109

8 Handle Grip 5PQ900116 44 Lower Rotor Housing 5PQ902027

9 Bolt, 3/8 x 1-1/2 5PQ000280 45 Bolt, 1/2 x 2 5PQ000452

10 Handle Grip 5PQ900116 46 Flange Bearing, 1-1/4 5PQ900112

11 Clamp Handle 5PQ902018 47 Lock Washer, 1/2 5PQ000840

12 Retaining Ring 5PQ902022 48 Nut, 1/2 5PQ000940

13 Clamp Pins 5PQ902021 49 Bolt, 1/2 x 1-1/2 5PQ000435

14 Nut, 3/8 5PQ000915 50 Flatwasher, 1/2 5PQ001055

15 Lock Washer, 3/8 5PQ000820 51 Bolt, 1/2 x 1-1/4 5PQ000420

16 Bolt, 3/8 x 4 All Thread 5PQ902033 52 Lock Washer, 1/2 5PQ000840

17 Bolt, 1/2 x 2 5PQ000452 53 Nut, 3/8 5PQ000915

18 Chute Retainer 5PQ902020 54 Lock Washer, 3/8 5PQ000820

19 Steel Locknut, 1/2 5PQ900144 55 Anvil Adjuster 5PQ900023

20 Steel Locknut, 3/8 5PQ900134 56 Anvil 5PQ900014

21 Chute Clamp 5PQ902019 57 Nut, 3/8 5PQ000915

22 Upper Rotor Housing 5PQ900048 58 Lock Washer, 3/8 5PQ000820

23 Bolt, 1/2 x 1-1/2 5PQ000435 59 Carriage Bolt, 3/8 x 1 5PQ000125

24 Steel Locknut, 1/2 5PQ900144 60 Bolt, 1/2 x 1-1/2 5PQ000435

25 Steel Locknut, 3/8 5PQ900134 61 Recessed Head Bolt, 3/8 x 1-3/4 5PQ900129

26 Rotor Bushing w/ Bolts 5PQ900104 62 Chipper Knife 5PQ900106

27 Bolt, 1/2 x 2 5PQ000452 63 Nut, 3/8 5PQ000915

28 Bearing Bracket 5PQ900015 64 Flatwasher, 3/8 5PQ001035

29 Flange Bearing, 1-1/2 5PQ900127 65 Hopper 5PQ900033

30 Lock Washer, 1/2 5PQ000840 66 Debris Curtain Bracket 5PQ900012

31 Nut, 1/2 5PQ000940 67 Debris Curtain 5PQ900126

32 Rotor Shaft 5PQ900039 68 Debris Curtain Clamp 5PQ900013

33 Key, 3/8 x 3/8 x 2 5PQ400857 69 Flatwasher, 3/8 5PQ001035

34 Pulley, 5” 3-Groove 5PQ700172 70 Bolt, 3/8 x 1-1/4 5PQ000275

35 Pulley Bushing w/ Bolts 5PQ900108 71 Chipper Rotor 5PQ900032

36 Lock Washer 1/4 N/A 72 Rotor Shaft Cover 5PQ900859

WC1105 Main Assembly
