FS UMC-GA1F1T User Manual

Model: UMC-GA1F2T
TP2/LNK PWRFX/LNK
TP1/LNK
TP1/LNK TP2/LNK FX/LNK PWR
LED Status Description
TP1/LNK
Green TP1 port is operating at 1000Mbps.
TP1 port is operating at 100Mbps.
TP1 port is operating at 10Mbps.
Red
FX/LNK
TP2/LNK
TP2 port is operating at 1000Mbps.
TP2 port is operating at 100Mbps.Red
Green
PWR Green The device is powered on.
Fiber port is actively sending or
receiving data.
Green
Blinking
Green
O Fiber port is linked down.
TP2 port is operating at 10Mbps.
Dual Color
1
Dual Color
1
NOTE:
Dual color: Two LED chips (in one package) are all
bright or blinking at the same time. The LED color resembles
orange.
1
Link through ber port is successfully
established, but no data transmission.
- 7 -EN

FS UMC-GA1F1T Specifications

General

Brand	FS
Model	UMC-GA1F1T
Category	Media Converter
Language	English
