FS UMC-GA1F1T - Panel LED Indicators - UMC-GA1 SC1 T Models; UMC-GA1 SC1 T-MM;SM LED Status and Description

- 8 -EN
Model: UMC-GA1SC1T-MM/UMC-GA1SC1T-SM
LED Status Description
TP/LNK
Green
The link through TP port is successfully
established.
The TP port is actively sending or
receiving data.
The TP port link is down.
Blinking
Green
FX/LNK
SPD
The TP port is operating at 1000Mbps.
The TP port is operating at 10/100Mbps.O
Green
PWR Green The device is powered on.
The ber port is actively sending or
receiving data.
Green
Blinking
Green
O The ber port link is down.
O
The link through ber port is
successfully established.
SPD PWRFX/LNK
TP/LNK
TP/LNK SPD FX/LNK PWR
