FS UMC-GA1SC1T-SM-FX - Connecting the SC Port

EN 9
Connecting the SC Port
NOTE: The converter is installed with the transceiver with SC
connector as default.
Connect one end of a ber optic cable to the SC port and the other
end to the ber network. TX and RX must be paired at both ends.
14
15 16 17
18 19 20 21 22 23
SPD
FX/LNK
PWR
TP/LNK
UMC-GA1SC1T-SM-FX
10/100/1000BASE-T to 100/1000BASE-X
Unmanaged Single Mode Gigabit Ethernet Media Converter
10/100/1000BASE-T to 100/1000BASE-X
Unmanaged Single Mode Gigabit Ethernet Media Converter
