FS UMC-GA1SC1T-SM - Bottom Panel (DIP Switch); UMC-GA1 F1 T DIP Switch Settings

Model: UMC-GA1F1T
Bottom Panel (DIP Switch)
ON
1 2 3 4
DIP
NOTE: LFP (Link Fault Pass Through) Function: If enabled,
when a device is connected to the converter and the TP/ber
line loses the link, the converter's ber will disconnect the link
of transmit.
ALS (Automatic Laser Shutdown) Function: If enabled, the
output power of the SFP transmitter will be automatically shut
down in case of ber break.
FX Reset: If enabled, when FX link is down, the power will
shut down, but a few second later the power will restart
automatically.
1
2
3
NO Function Status Description
1
2
3
4 FX Speed Set
OFF Disable
Disable
Disable
FX 1000M
FX 100M/1000M
Enable
Enable
Enable
ON
OFF
ON
OFF
ON
OFF
ON
LFP Function1
FX Reset
3
ALS Function
2
(Only for SFP)
- 10 -EN
