Hardware Overview
Front Panel Ports
UMC-GA1F1T
RJ45 Port
1000M PWRFX/LNK
TP/LNK
SFP Port
Ports Description
RJ45
SFP
10/100/1000Base-T RJ45 port for Ethernet connection
Hot swappable SFP port for 1G ber connection
UMC-GA1F2T
TP2/LNK PWRFX/LNK
TP1/LNK
RJ45 Port RJ45 Port SFP Port
- 4 -EN
