FScurtis RNP75 - DRYER SYSTEM MONITOR (DSM) DETAILS; DSM Indicators and Scales; DSM Adjustment Knobs and Test Button

5
2
1
10 9 8
7
6
543
Dryer System Monitor
(Models RNP200, RNP250, RNP300, RNP400 and RNP500)
1. On/OffSwitch:Pressthetopoftheswitch(I)toturn
thedryeron.Pressthebottomoftheswitch(O)to
turnthedryeroff.Whenthedryerison,theswitchis
illuminated.
2. ThisisagraphicsymbolfortheAirDryercompressor.
Itsimplyindicatesthattheswitchisusedtoturnthe
compressor(dryer)onandoff.
3. Partofthegraphicforthedewpointtemperature
scale.Thesnowflakeindicatesthelow(cold)endof
the scale.
4. Mainportionofthegraphicforthedewpoint
temperaturescale.Greenindicateslow,orange
indicatesmedium,redindicateshigh.
5. Partofthegraphicforthedewpointtemperature
scale. The thermometer indicates the high (hot) end
ofthescale.
6. Six(6)LEDsthatindicatedewpointtemperature
accordingtothegraphicscaleabovetheLEDs.The
colorofeachLEDmatchesthecoloredbars
7. Adjustmentknobforthedrainvalveopentime.The
values on the dial correspond to the time in seconds
that the valve is open in each drain cycle.
8. Adjustmentknobforthedrainvalveclosedtime.The
values on the dial correspond to the time in minutes
that the valve is closed in each drain cycle.
9. LEDtoindicatewhenthedrainvalveisopen.
10. Draintestbutton.Whenthebuttonispressed,the
drainvalveopensforthetimecorrespondingtothe
settingonitem7.
