FT S2 - Introduction; Part Name Identification

Introduction
S2
S2 strobelight offer red, blue, yellow three colors for combination. It supports quick-release
installation. With 5V to 30V wide voltage input, it supports physical key switching and it's
compatible with OSDK and other interfaces. Support DJI Pilot, brightness adjustment, flash
frequency adjustment, one-click switching flash modes. The applicatioin scenarions can be
emergency rescue, fire, public security, maritime and other fields.
Part Name
1.
Lights power cable
Connect the lights to the control template.
2.
Quick release snaps
Install the lights.
3.
Lights
3 colors lights（red, yellow and blue)
4.
Button
Physical button to switch modes
5.
T-ypec Interface
Connect the lights.
6.
DJI SDK
Interface
Connect
Matrice30 and Matrice300
series SDK interfaces.
7.
Bracket
Fix the control template
1
6
3
2
5
7
4/10
4
