PARTS LIST
Part no. Description QTY UNIT
A Computer 1 PC.
A-1 Screw 4 PCS.
B Handlebar assembly 1 SET
B-1 Handlebars 1 PC.
B-2 Foam grip 1 PC.
B-3 End cap for handlebars 2 PCS.
B-4 Pulse senosr 2 PCS.
B-5 Handpulse 4 PCS.
C Handlebar post assembly 1 SET
C-1 Cabler, upper part 1 PC.
C-2 Screw 4 PCS.
C-3 Bottle holder 1 PC.
C-4 Handlebar cover 1 PC.
D-1 Screw 4 PCS.
D-2 Flat washer 2 PCS.
D-3 Circle washer 2 PCS.
E Mainframe 1 SET
E-1 Seat post knob 1 PC.
E-2 Screw 5 PCS.
E-3 Screw 4 PCS.
E-4 Curved washer 1 PC.
E-5 Flat washer 1 PC.
E-6 C-type ring 1 PC.
E-7 Bearing 2 PCS.
E-8 Seat post bushing 1 PC.
E-9 Crank arm ( Left ) 1 PC.
E-10 Crank arm ( Right) 1 PC.
E-11 Sensor 1 PC.
E-12 Sensor holder 1 PC.
E-13 Flat washer 1 PC.
E-14 Screw 1 PC.
E-15 DC wire 1 PC.
E-16 Driving belt 1 PC.
