FT450/FT550 Sportsman Data logging A Harness
5.3 Smart Coil harness
components (Sold Separately)
This extension allows the use of 8 individual
Smart COP coils(w/ integrated igniter) on the
ignition system, it has 8 metri-pack 150.2
connectors, 2 relays and 2 fuses.
- Main Inner 16-way circular: The
Main connector is a 16-way Tyco CPC
connector which contains the outputs to
the 8 individual coils.
- 8x Smart coil connectors: 8 Smart
COP coil outputs (metri-pack 150.2
connectors) which allows wasted spark
ignition.
- 2x 30A Relay: These Relays will power
the coils.
- Gray Outputs connector: This connector
must be plugged to the “IGNITION
EXPANSION” connector at the Sportsman
A Harness.
