FT450/FT550 Sportsman Data logging A Harness
Engine
1 - CPC Connector
2 - O2 Sensor R
3 - O2 Sensor L
4 - Unterminated wires CAM and Crank
5 - Oil Pressure Connector
6 - Fuel Pressure Connector
7 - Engine Temperature Connector
8 - Transmission Temperature Connector
9 - Powered CAN
1
2
3
4
5
6
7
8
9
To Next Page
