Paper Jams
553
Problem Solving
15
4
Push down the green handle A1 in the direction
of the arrow several times to eject the paper
upward.
5
Remove the paper in the direction of the arrow.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
6
Push the center of the Cover A to close it gently, and then close the Tray 5.
When using the green handle A2
1
Open the Tray 5 (Bypass).
îš„ When the Side Tray (optional) is installed
Remove paper from the side tray.
Note • If opened with the paper loaded on the side
tray, Cover A will not be easily folded up
when closed.
2
Pull the release handle of Cover A, and open
the Cover A.
To Next Page
