10 Maintenance
228
Determining the Density Setting
The density setting value is determined by comparing the printed calibration chart with the
density of the Color Samples for Calibration included with the device.
Look for the density which is close to the density of the Color Samples for Calibration from
among the adjustment patches of the calibration chart.
1
Fold the printed halftone adjustment chart in a peak fold along the vertical guide line
(dotted line) of the color to adjust.
2
Match the density of the halftone adjustment chart to adjust with the location of the same
density on the color samples for halftone adjustment.
(Ex: Low density (L). To adjust a low density (L), match Low with Low.)
Color Sample
Calibration Chart
To Next Page
