Replacing Consumables
37
37
1. Open the Front Cover by pulling the cover towards you.
2. Open the Bypass Tray, and
3. Open Cover A while lifting up the release lever.
Replacing Drum Cartridge
4. Lift up the colored lever, and slide the Drum Cartridge out until the handle on
top of the cartridge can be lifted.
5. Grasp the handle and remove the cartridge from the machine.
To install new Drum Cartridge
1. Remove the new Drum Cartridge from the box.
2. Carefully remove the protective sheet from the cartridge by peeling the tape
up and slowly pulling the sheet out.
3. Place the cartridge in position and slide it into the machine until it clicks into
place.
4. Remove the cartridge seal completely by pulling the tape straight out and
make sure the cartridge remains fully seated to the rear.
5. Close Cover A until it latches, and then close the Bypass Tray.
6. Close the Front Cover.
1
2
3
4
5
Consumables
For used cartridges disposal, please call us @ 1-300-88-1163 for collection.
