Replacing Consumables
38
38
Consumables
Replacing Staple Cartridge (Finisher)
1. Open the Finisher Front Door
2. Rotate the Stapling Unit to the right and pull out on the Staple Cartridge handle
3. Remove the used cartridge
4. Unpack and install the new cartridge.
5. The cartridge will click into place when it is installed correctly.
6. Insert the cartridge into the machine. Close the Finisher Front Door.
Replacing Staple Cartridge (Booklet Finisher)
1. Open the Finisher Front
Door.
2. Pull Booklet Maker
access handles and pull out
the Stapling Unit.
3. Squeeze the handles and
pull to remove the used
cartridge.
4. Unpack and install the
new cartridge. The
cartridge will click into place
when it is install ed
correctly.
Return the Stapling Unit to
its original position.
Close the Finisher Fron t
Door.
4
5
6
1
2
3
1
2
3 4
For used cartridges disposal, please call us @ 1-300-88-1163 for collection.
