Stapler Faults
547
Problem Solving
14
Staple Jams in Staple Cartridge (For Finisher-A1)
This section describes how to clear staple jam occurred in the staple cartridge of the
Finisher-A1 (optional).
1 Make sure that the machine is not operating,
and open the finisher front cover.
2 Take the staple cartridge out of the machine.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
3 After you take out the staple cartridge, check
inside of the finisher for any remaining
staples.
4 Pull up the metal part of the staple cartridge
as shown in the illustration.
5 Remove the jammed staples (1), and then
return the metal part pulled up in step 4 to
the original position (2).
CAUTION
Be careful in removing jammed staples.
To Next Page
