3 Maintenance
68
Maintenance
3
7 Insert the front two points of the new drum
cartridge with protective cover in the holes
on the machine.
Note • Insert the two points as shown in the
illustration on the right.
8 Pull out the black paper while holding the
protective cover with one hand. While doing
so, keep the two points inserted in the holes.
9 Grasp the tab on top of the cartridge and
slide it toward the machine while holding the
protective cover with one hand.
10 Slide the tab until it stops.
11 Carefully remove the protective cover.
12 Push the drum cartridge straight in the
housing until it stops.
Note • Place the protective cover into the box.
