Fuji Xerox DocuCentre-V C5576 Administrator's Guide

Specifications
657
Appendix
16
*1 : For punching, Punch Unit 2/4H CD1 (optional) or Punch Unit US 2/3H CD1 (optional) is required.
*2 : You can switch the number of punch holes between 2 holes and 4 holes with the Punch Unit 2/4H CD1 (optional), and US 2
holes and US 3 holes with the Punch Unit US 2/3H CD1 (optional).
*3 : The Fold Unit CD1 (optional) is required.
*4 : This is for the Folder Unit CD1 (optional). The another power source is required when the Folder Unit CD1 is installed.
*5 : When the Transport Unit H1 (optional) is installed and the extension tray is fully extended.
Staple Capability : 50 sheets (90 gsm or less)
Note • When the C3 Finisher Staple Unit 65 Sheets (optional) is installed, at
the maximum of 65 sheets can be stapled. Depending on the paper
type, copies may not be aligned or stapled properly.
• When using with Folder Unit CD1, Z-fold sheets can be stapled;
however, since one Z-fold sheet of A3 or 11 x 17" paper becomes the
same in thickness as 10 sheets of unfold paper, the maximum number
of Z-fold sheets of A3 or 11 x 17" paper that can be stapled is reduced.
When converted into unfold sheets of paper that can be stapled, one
Z-fold sheet of A3 or 11 x 17" paper is equivalent to 10 sheets of
unfold paper and one Z-fold sheet of other size of paper is equivalent
to 20 sheets of unfold paper.
If the curl in the paper is very strong, the output paper may not be
stapled properly.
Paper size : Maximum: A3, 11 x 17"
Minimum: B5
Position : 1 position or 2 positions
Important • When using P paper
Punch
*1, *2
Number of holes : 2/4 holes, US 2/3 holes
Paper size : A3, 11 x 17", B4, A4
*
, A4 , 8.5 x 11", 8.5 x 11" ,
B5 , 7.25 x 10.5", 8 x 10", 16K ,
Cover A4 , 9 x 11" , 215 x 315 mm, 8.5 x 13",
Legal (8.5 x 14"), 11 x 15", 8K
* : The 3 holes (optional) are not available.
Paper weight : 52 - 200 gsm
Important • When using P paper
Folding
*3
Z-Fold
Paper size: A3, B4, 11 x 17"
Paper weight: 60 to 90 gsm
C-Fold
Paper size: A4, Letter (8.5 x 11")
Paper weight: 60 to 90 gsm
Power Supply AC 220 - 240 V ±10% / 110 V ±10%, 0.5 A/0.9 A / for both 50/60 Hz
Maximum Power
Consumption
*4
100 W
Dimensions Width 730 x Depth 589 x Height 1,056 mm
Width 965 x Depth 726 x Height 1,056 mm (with the Fold Unit CD1 and a
punch unit)
Weight
*5
44 kg
98 kg (with the Fold Unit CD1 and a punch unit)
Space Requirement (with
the main unit)
Width 1,774 x Depth 699 mm (Main unit + C3 Finisher)
Width 2,009 x Depth 729 mm (Main unit + C3 Finisher + Fold Unit CD1)
