EN-3ENGLISH
Changes and Additions
■ SYNC TERMINAL
The following options are
available when a  ash unit is
connected via the sync ter-
minal.
MODE
SYNC TERMINAL
ADJUST
END
A
Flash control mode: Choose from the options below.
• M: A trigger signal is transmitted from the sync terminal
and hot shoe when a picture is taken. Choose a shutter
speed slower than the sync speed (/ s); even slower
speeds may be required if the unit uses long  ashes or
has a slow response time.
• OFF: The sync terminal and hot shoe do not transmit a
trigger signal.
B
Sync: Choose whether the  ash is timed to  re immediately
after the shutter opens (1ST CURTAIN) or immediately be-
fore it closes (2ND CURTAIN). 1ST CURTAIN is recommended in
most circumstances.
The Sync Terminal
The Sync Terminal
Use the sync terminal to connect
Use the sync terminal to connect
 ash units that require a sync cable.
 ash units that require a sync cable.
■ SHOE MOUNT FLASH
The following options are
available with optional shoe-
mounted  ash units.
MODE
SHOE MOUNT FLASH
ADJUST
END
A
Flash control mode: The  ash control mode selected with the
 ash unit. This can in some cases be adjusted from the
camera; the options available vary with the  ash.
• TTL: TTL mode. Adjust  ash compensation (
B
).
• M: The  ash  res at the selected output regardless of sub-
ject brightness or camera settings. Output in some cases
can be adjusted from the camera (
B
).
• MULTI: Repeating  ash. Compatible shoe-mounted  ash
units will  re multiple times with each shot.
• OFF: The  ash does not  re. Some  ash units can be
turned o from the camera.
B
Flash compensation/output: The options available vary with
 ash control mode.
• TTL: Adjust  ash compensation (the full value may not
be applied if the limits of the  ash control system are
exceeded). In the cases of the EF-X20, EF-20, and EF-42,
the selected value is added to the value selected with
the  ash unit.
• M/MULTI: Adjust  ash output (compatible units only).
Choose from values expressed as fractions of full pow-
er, from / (mode M) or / (MULTI) down to / in incre-
ments equivalent to / EV. The desired results may not
be achieved at low values if they exceed the limits of the
 ash control system; take a test shot and check the results.
