REFRIGERANT SYSTEM DIAGRAM
2-Way
valve
Strainer
Strainer
3-Way
valve
Muffler
Muffler
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
AOH9LFBC
(2Pass)
AOH12LFBC
(4Pass)
Compressor
Cooling
Heating
ASH12LSBCW / AOH12LFBC
Models : ASH9LSBCW / AOH9LFBC
2005.02.01 3
