Datasheet ⏐ Issue: December 2005⏐ SCENIC Edition X103 SFF Page 2 / 3
SCENIC Edition SCENIC Edition
X103 SFF X103 SFF
Order codes VFY:SCED103*61A1* VFY:SCED103*61F1*
*depending on country configuration VFY:SCED103*61A3* VFY:SCED103*61F3*
Mainboard
Chipset SiS661FX / SiS964
Mainboard Number PTM661FX-AA
Mainboard form factor µATX
Processor socket LGA 775
Front side bus resp. system bus support 800 MHz
BIOS version Award
Flash EPROM BIOS update by software x
Recovery BIOS -
Processor
Intel Celeron D341 P4 HT 521
Second level cache 256 KB 1 MB
Front side bus (FSB) 533 MHz 800MHz
Memory *depending on configuration
Memory 256 MB 512 MB DDR
DIMM slots 2
Max. capacity 2GB
Interfaces
Mouse/keyboard (PS2) x/x
Serial (9pi, 16 byte FIFO, 16550 compatible) x
Second serial port -
Parallel (25pin with EPP and ECP) x
Display (15 pin, VGA) x
Display (DVI) -
Micro (mono) rear x
Line in (stereo) rear x
Line out (stereo) rear x
Micro (mono) front x
Headphone in front x
LAN RJ45 x
Universal Serial Bus (USB 2.0) in total 6
therefore USB rear 4
USB front 2
USB internal -
LAN on board
10/100/MB/s Realtek RTL8201BL
PXE x
BootP -
Audio on board
AC97 Realtek ALC655
High definition audio -
I/O controller onboard
Fast IDE/Ultra DMA-100 bus master capability for 4 drives
Serial ATA 2
Raid 1/0 -
Drive bays
internal 3,5'' 1
external 3,5'' 1
external 5,25'' 1
Floppy disk drive 1.44 MB standard x
Hard disk drives
Serial ATA 80 GB
Optical drives
ATAPI 16/48- speed ATAPI DVD CDRW/DVD Combo drive
Slots
PCI 3 x low profile
AGP 8x 1 x low profile
PCI Express 1x -
Graphic on board
Shared memory depending on driver 32MB or 64 MB
Resolution (color depth up to 32 Bit/pixel)
800 x 600 (recommended / max*) 85 / 120 Hz
1024 x 768 (recommended / max*) 85 / 120 Hz
1280 x 1024 (recommended / max*) 85 Hz
1600 x 1200 (recommended / max*) 75 Hz
* refresh rates reflect the max. graphics capabilities. Video
quality can be deteriorated when using maximum settings.
Electrical values
Rated voltage 100 - 127 / 200 - 240 V
Rated frequency 50-60 Hz
Max. output of power supply 160 W
Monitor outlet -
Power consumption for standard configuration (W)
Peak (running app. CD in use) 135 W
