6. RIGHT PANEL removal
Remove the 9 mounting screws.
Remove the RIGHT PANEL by sliding upward.
03-07
Hook
Hook
Hook
RIGHT PANEL
Replaceable Component
Thermistor (Heat exchanger temp.)
