Remove the 1 mounting screw.
Remove the INVERTER BOX COVER upward.
Remove the connector and cords.
03-13
Hook (2 places)
INVERTER BOX COVER
CN1 (Black/Brown/Red)
W4 (Black)
W5 (White)
Twist W4 and W5
2 times or more.
E
F
VIEW - E
