Fujitsu ABY18UBBJ User Manual

PARTS LIST
INDOOR UNIT
ABY24UBBJABY18FBBJ ABY18UBBJ ABY24FBBJ
Ref. Description
Part number
69 Louver 9358561010 9358561010 9358561010 9358561010
8-1 Air Filter 9358567029 9358567029 9358567029 9358567029
34 Capacitor (Fan Motor) 9703306044 9703306044 9703306044 9703306044
36-2 Cord Holder Metal 9356362008 9356362008 9356362008 9356362008
56 Sirocco Fan Assy 9385258006 9385258006 9385258006 9385258006
67 Rubber (Vibration-proof) 9385102002 9385102002 9385102002 9385102002
68 Cap 9358563007 9358563007 9358563007 9358563007
108 Base Assy 9359061038 9359061038 9359061038 9359061038
109 Casing 9358543009 9358543009 9358543009 9358543009
124 Kit (Dew Proof Plate Sub Assy) 9372673010 9372673010 9372673010 9372673010
126 Motor Fixing Table Assy 9358591000 9358591000 9358591000 9358591000
127 Drain Hose Assy 9359242000 9359242000 9359242000 9359242000
138 Kit (Separate Wall A Sub Assy) 9372666012 9372666012 9372666012 9372666012
146 Evaporator Assy KB07 ---------
---------
93625130369362513036 9362513036
146 Evaporator Assy KB45 9362513029 --------- ---------
160 Drain Pan Assy 9358568002 9358568002 9358568002 9358568002
164 Fan Motor Assy-IN MFA-24JTT --------- --------- 9601527015 9601527015
164 Fan Motor Assy-IN MFA-18JTT 9601527022 9601527022 --------- ---------
173 Hanger Bracket-L 9358596005 9358596005 9358596005 9358596005
174 Hanger Bracket-R 9358595008 9358595008 9358595008 9358595008
184-1 Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805
196-1 Clamp SKB-3M 312300787605 312300787605 312300787605 312300787605
210 Main Relay 9353611017 9353611017
211 Cushion Rubber 313806328306 313806328306
223 Control Box 9358600016 9358600016 9358600016 9358600016
---------
---------
---------
---------
234 Thermistor Assy-Room 9703299087 9703299087 9703299087 9703299087
235 Thermistor Assy-Pipe 9900022020 9900022020 9900022020 9900022020
9704557216
(EZ-002YWSE-C)
9704557223
(EZ-00211HSE-C)
9704557131
(EZ-002TWSE-C)
9704557148
(EZ-00210HSE-C)
236 Controller PCB Assy
240 Remote Control AR-JW1 --------- 9371190013 --------- 9371190013
240 Remote Control AR-JW2 9371190020 --------- 9371190020 ---------
320 Flap (Upper)-F 9358538012 9358538012 9358538012 9358538012
321 Kit (Flap (Lower) Sub Assy) 9372671016 9372671016 9372671016 9372671016
338 Motor Fixture 9358594001 9358594001 9358594001 9358594001
361 Bushing 9357942001 9357942001 9357942001 9357942001
361-2 Bushing-B, Plastic 9358554005 9358554005 9358554005 9358554005
361-3 Bushing-C, Plastic 9358553008 9358553008 9358553008 9358553008
365-1 Special Screw 9359092001 9359092001 9359092001 9359092001
365-2 Special Screw 9359091004 9359091004 9359091004 9359091004
381 Locking Spacer, KGLS-4S 313209391506 313209391506 313209391506 313209391506
385 Indicator PCB Assy 9701873012 9701873012 9701873012 9701873012
407 Motor Rod 9358560006 9358560006 9358560006 9358560006
408 Louver Link 9358556009 9358556009 9358556009 9358556009
416 Insulation (Panel)-A 9358574003 9358574003 9358574003 9358574003
417 Insulation (Panel)-B 9358914007 9358914007 9358914007 9358914007
418 Insulation (Flap Base) 9358572009 9358572009 9358572009 9358572009
252014.02.06
443 Arm Bracket 9359281009 9359281009 9359281009 9359281009
470 kit (Separate Wall B Sub Assy) 9373448013 9373448013 9373448013 9373448013
472 Grille Support 9358602003 9358602003 9358602003 9358602003
473 Filter Bracket 9358607008 9358607008 9358607008 9358607008
488 Grill-F 9358532010 9358532010 9358532010 9358532010
422
Clamp NK-10N 9359183006 9359183006 9359183006 9359183006
