 Unit: kW, °C
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ACUH07LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
-5.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
0.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
5.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
10.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
15.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
20.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
25.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
30.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
35.0 1.72 1.16 1.95 1.33 2.05 1.53 2.20 1.71 2.35 1.88 2.42 2.15
40.0 1.63 1.04 1.84 1.19 1.94 1.37 2.08 1.53 2.22 1.68 2.29 1.92
46.1 1.54 0.93 1.74 1.06 1.83 1.22 1.96 1.37 2.10 1.49 2.16 1.71
MODEL: ACUH09LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
-5.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
0.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
5.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
10.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
15.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
20.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
25.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
30.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
35.0 2.21 1.47 2.49 1.67 2.63 1.93 2.81 2.17 3.01 2.37 3.10 2.71
40.0 2.09 1.32 2.36 1.50 2.49 1.73 2.66 1.94 2.85 2.12 2.93 2.43
46.1 1.97 1.17 2.22 1.33 2.35 1.54 2.51 1.73 2.68 1.89 2.77 2.16
MODEL: ACUH12LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
-5.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
0.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
5.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
10.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
15.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
20.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
25.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
30.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
35.0 2.94 1.93 3.32 2.20 3.50 2.54 3.75 2.85 4.01 3.12 4.13 3.57
40.0 2.78 1.73 3.14 1.97 3.32 2.27 3.55 2.55 3.79 2.79 3.91 3.20
46.1 2.62 1.54 2.97 1.76 3.13 2.02 3.35 2.27 3.58 2.48 3.69 2.85
MODEL: ACUH18LUAS1
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
-5.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
0.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
5.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
10.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
15.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
20.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
25.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
30.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
35.0 4.41 2.67 4.99 3.05 5.26 3.51 5.63 3.94 6.02 4.31 6.20 4.94
40.0 4.17 2.39 4.72 2.73 4.97 3.14 5.32 3.53 5.69 3.86 5.87 4.42
46.1 3.94 2.13 4.45 2.42 4.69 2.79 5.02 3.14 5.37 3.43 5.53 3.93
- 261 -
6-2. Cooling capacity 6. Capacity table
